SS1-0-102-A04-04-Q-N-RS

SS1-0-102-A04-04-Q-N-RS SS1-0-102-A04-04-Q-N-RS SS1-0-102-A04-04-Q-N-RS SS1-0-102-A04-04-Q-N-RS SS1-0-102-A04-04-Q-N-RS

Technical characteristics

1. Specification: 3A 125VAC; 1A 250VAC 0.4 VA maximum. @ 20 V AC or DC maximum 2. Contact resistance: ＜ 20m Ω 3. Insulation resistance: 500VDC, not less than 1000m Ω 4. Withstand voltage: 1000VAC, 1 minute 5. Working temperature: -30 ° C~+85 ° C 6. Electrical life: over 10000 cycles 7. Mechanical life: over 40000 times

Material

Base: PPA (UL94V-0) Rubber head: high-temperature nylon, Shell: brass/silver plated Contact piece/terminal: Copper alloy, silver or gold plated
